Air Washer

Product Description

Our enterprise has gained immense recognition in manufacturing, exporting and supplying a quality assured array of Air Washer. Our offered washer is widely used for removing dust particles from the air. The washer provided by us is manufactured by making use of excellent grade components with the aid of advanced techniques in line with international quality standards. Apart from this, clients can avail this Air Washer from us at rock bottom prices.

Features:

Specifications:

Capacity Availiable for Air Washer : 2000 to 40000 CFM with single Blower & 4000 to 80000 CFM with Single & multiple blowers

Base Frame of Air Washer: The total assembly is mounted on a horizontal member of heavy Mild steel channel.

Air Washer Fan Section : Constructed in GI/SS Sheet with Inspection Doors.

Wet Section : Constructed in GI/SS Sheet.

Water Tank Structure of Air Washer Constructed in GI with Frp coated/SS

Air Washer BLower : Dynamically Balaced Forward Curved, DIDW Type Make Dynamic / Imported.

CellulosePaper Pad :Imported HUTEK, Munters

Air Washer Electric Motor :  Three Phase, TEFC squirrel cage induction motor of standard makes (Crompton, ABB and Kirloskar etc.).

Drive Pulley : V-Groove with/without Taper Lock hub.

V-Belts : Fenner make.

Pump: Monoblock make Crompton / Kirloskar.

Filter used in Air Washer: HDPE/Aluminum/GI Mesh Filter, Micro Vee, Hepa as per requirement.

Pipe Fittings in Air washer : PVC piping with all Necessary fittings such as float valve, quick  fill, overflow & drain ports.
